| Dimensions & Weight | |
|---|---|
| Kerb Weight | 132 kg |
| Length | 1990 mm |
| Width | 770 mm |
| Height | 1030 mm |
| Ground Clearance | 160 mm |
| Wheelbase | 1330 mm |
| Seat Height | 790 mm |
| Top Speed | - |
| Chassis | |
|---|---|
| Type | Diamond Type |
| Engine | |
|---|---|
| Displacement | 149 |
| Cylinders | 1 |
| Valves | 2 |
| Power (BHP) | 13 bhp @ 8,000 rpm |
| Torque (NM) | 12.80 Nm @ 6,000 rpm |
| Cooling System | Air Cooled |
| Ignition | Transistor Controlled Ignition |
| Transmission | |
|---|---|
| Transmission Type | Manual |
| No of gears | 5 |
| Drivetrain | |
|---|---|
| Drive Type | Chain Drive |
| Fuel | |
|---|---|
| Fuel Type | Petrol |
| Fuel efficiency | 58 kmpl |
| Fuel delivery system | Fuel Injection |
| Fuel tank capacity | 12 litres |
| Suspensions, Brakes, Steering & Tyres | |
|---|---|
| Suspension Front | Telescopic |
| Suspension Rear | Swingarm |
| Wheel Size (inches) | 17 inches |
| Tyre Size Front | 100/80-17M/C(52P) |
| Tyre Size Rear | 140/60-R17M/C(63P) |
| Brakes Front | Yes |
| Brakes Rear | No |
| Electrical | |
|---|---|
| Battery | 12V,4.0AH(10H) |
| Headlight Bulb Type | 12V, 35/35W |
| Electric System | 12V DC |
| Speedometer | Digital |
| Tachometer | Yes |
| Tripmeter | Yes |
| Electric Start | Yes |
| Pillion seat | Yes |
| Stand warning/indicator (Stand Alarm) | No |
| Engine kill switch (Killswitch) | No |
| Clock | No |
| Headlight type | Halogen Bulb Type |
| Tail light type (Brake/Tail Light) | 12V,21/5W 1 |
| ABS (Antilock Braking System) | No |
| Traction Control | - |
| Alloy wheels | Yes |
| Handle type | - |
| Pass Light | Yes |
