Dimensions & Weight | |
---|---|
Kerb Weight | 104 kg |
Length | 1795 mm |
Width | 675 mm |
Height | 1124 mm |
Ground Clearance | 128 mm |
Wheelbase | 1270 mm |
Seat Height | 775 mm |
Top Speed | - |
Chassis | |
---|---|
Type | Steel pipe underbone |
Engine | |
---|---|
Displacement | 113 |
Cylinders | 1 |
Valves | 2 |
Power (BHP) | 7.10 bhp @ 7,500 rpm |
Torque (NM) | 8.10 Nm @ 5,000 rpm |
Cooling System | Air Cooled |
Ignition | CDI(Capacitor Discharge lgnition) |
Transmission | |
---|---|
Transmission Type | Automatic |
No of gears | - |
Drivetrain | |
---|---|
Drive Type | Belt Drive |
Fuel | |
---|---|
Fuel Type | Petrol |
Fuel efficiency | 62 kmpl |
Fuel delivery system | Carburetor (pressure diaphragm type) |
Fuel tank capacity | 5.20 litres |
Suspensions, Brakes, Steering & Tyres | |
---|---|
Suspension Front | Telescopic |
Suspension Rear | Unit swing |
Wheel Size (inches) | 10 inches |
Tyre Size Front | 90/100-10 (53J) |
Tyre Size Rear | 90/100-10 (53J) |
Brakes Front | No |
Brakes Rear | No |
Electrical | |
---|---|
Battery | Maintenance Free |
Headlight Bulb Type | 12V 35W/35W |
Electric System | 12V DC |
Speedometer | Analogue |
Tachometer | No |
Tripmeter | No |
Electric Start | Yes |
Pillion seat | Yes |
Stand warning/indicator (Stand Alarm) | Yes |
Engine kill switch (Killswitch) | No |
Clock | No |
Headlight type | Halogen Bulb Type |
Tail light type (Brake/Tail Light) | - |
ABS (Antilock Braking System) | No |
Traction Control | - |
Alloy wheels | No |
Handle type | - |
Pass Light | No |
